Parts of a Recurve Bow: Every Piece, Named and Explained
A recurve bow is three pieces — a rigid riser and two flexible limbs — plus a string. Here's what every part does, from the plunger hole to the ILF dovetail, and which ones actually matter when you buy.
By the Archery Care Editorial Team
Watch it done
Reputable tutorials that demonstrate this, hand-picked by Archery Care. The walkthroughs are the creators’ own — we just point you to the good ones (and, where they added chapters, straight to the moment that matters).
A recurve bow breaks down into three pieces: a riser in the middle and two limbs, one seated into each end. String it and you've got the whole machine. Everything else you see hanging off an Olympic bow — sight, stabilizers, clicker, plunger — screws into threaded holes the riser already has.
That takedown design is the point. You can fly with your bow in a normal suitcase. You can buy one riser with 20-pound limbs and work up to 36 pounds over a few years without replacing anything but the limbs.
Here's every part and what it actually does.
Material matters more than most beginners expect. Dacron strings stretch more and come standard on entry-level bows — forgiving, and safe on any limb. Low-stretch fibers like Dyneema and Spectra (sold under names like Fast Flight) waste less energy, but don't put one on limbs that aren't rated for it.
Skip memorizing the rest. Once you know the riser holds everything, the limbs do the work, and the string's serving and nocking point keep each shot identical, the parts wall at any archery shop stops being intimidating.
The riser
Start with the riser. It's the handle section — aluminum or carbon on target bows, wood on traditional one-piece bows — and it does no springy work at all. A rigid chassis, nothing more. Risers come in 23, 25, and 27 inch lengths, with 25 inches the adult standard.
Working from your hand outward, you'll find:
- Grip — the shaped section your palm pushes against. On most metal risers it's a separate plastic or wood piece you can swap or sand to fit your hand. Wooden risers have it carved in.
- Sight window — the cutout above the grip that lets the arrow sit near the bow's centerline instead of beside it.
- Arrow shelf — the horizontal ledge at the bottom of the sight window. Hunters and barebow archers shoot straight off it; target archers ignore it and stick a thin wire rest on the riser face instead.
- Plunger hole — a threaded hole through the riser just above the shelf. The plunger (a spring-loaded button) lives here and cushions the arrow's sideways flex on release. Most beginner risers include the hole even if you never fit one. Good — it means you can tune later.
- Bushings — threaded metal inserts for accessories: a stabilizer bushing below the grip, sight-mount holes on the back, often a clicker position too. The threads are standardized across brands, so a cheap riser takes the same accessories an expensive one does.
- Limb pockets — the slots at top and bottom where the limbs seat.
Limbs
Limbs are the engine. They bend as you draw, then snap forward and dump that stored energy into the arrow. Construction is typically a wood or foam core faced with fiberglass or carbon — carbon-faced limbs cost more and recover faster.
Check the numbers printed on the limb face before anything else. Manufacturers measure draw weight at a 28-inch draw on a 25-inch riser, so a limb marked 34 pounds delivers 34 pounds in exactly that setup. Draw an inch shorter or longer and the weight shifts by roughly 2 pounds. Riser length matters too: put 42-pound medium limbs on a 23-inch riser and they pull about 44.
Limbs come in short, medium, and long. On a 25-inch riser that builds a 66, 68, or 70-inch bow — and which one suits you depends on your draw length, so measure that first. A draw length calculator gets you close enough to order.
One quiet detail: the bottom limb is usually set slightly stiffer than the top, because your hand and fingers don't sit at the bow's exact center. The difference is called tiller, and most Olympic shooters run about 1/8 inch of positive tiller.
Starting out? Most coaches put new adult archers on 20 to 24 pounds. Your back and shoulders will complain the first couple of weeks regardless — that's normal, not a sign you bought wrong.
The string
Look closely at a bowstring and you'll find four parts, not one:
- String loops — the woven ends that hook into the grooves at each limb tip. The top loop is made larger so it can slide down the limb when the bow is unstrung.
- End servings — tight thread wrapping that protects the string where the loops take the load.
- Center serving — the thicker wrap in the middle where you nock arrows and place your fingers or tab. It takes the abuse so the string strands underneath don't.
- Nocking point — a brass crimp or a few wraps of tied-on serving thread marking exactly where the arrow clips on. Same spot every shot, or your vertical grouping falls apart.
ILF fittings
ILF stands for International Limb Fit, and it's the closest thing archery has to a universal standard. The limb's butt end has a U-shaped slot that slides under the riser's limb bolt, plus a dovetail detent that clicks into the limb pocket. No tools. Push the limb in until it clicks, string the bow, done.
The payoff is cross-brand freedom: any ILF limb fits any ILF riser. A Sanlida Miracle X10 riser will happily take WIAWIS or Galaxy limbs, and the limb bolts double as adjusters — a few turns changes draw weight and tiller without buying anything.
Two caveats. Hoyt's Formula system, used by risers like the Formula XD, is a separate fitting — Formula limbs and ILF limbs don't interchange, though Hoyt's other risers such as the Xceed take ILF. And budget takedowns like the Samick Sage use simple bolt-on limbs instead: cheaper, solid for a first bow, but you're locked into Sage-pattern limbs when you upgrade.
What to check before you buy
Before you spend money, run through three things.
- Bow length — riser length plus limb length, matched to your draw length. Get the draw measurement first.
- Limb fitting — ILF gives you the widest upgrade path; proprietary bolt-on systems are fine if the price gap pays for lessons instead.
- The boring holes — plunger hole, stabilizer bushing, sight mounts. If the riser has them, it can grow with you. If it doesn't, it can't.
Real questions archers ask about the parts of a recurve bow
Mined from public archery communities (June 2026); answered by Archery Care using our scored data. Source links go to the original discussions.
Which parts come standard on a recurve, and which do I have to buy separately?
Here's the part that trips up almost every newcomer: a riser and limbs are a bare bow, not a ready-to-shoot one. The string usually comes with a beginner package, but the rest you add yourself. The essentials are an arrow rest and a plunger (the spring button that sets center shot), plus a nocking point on the string. After that come the sight, a basic stabilizer, a finger tab and an armguard. The clicker and sights only live on Olympic-style setups. Budget for the accessories, not just the riser and limbs, or you'll end up with a handsome handle and nowhere to rest the arrow.
What are all those threaded holes drilled into the riser for?
Look at a metal riser and you'll spot several threaded bushings: a big one low on the front for the long-rod stabilizer, smaller ones front and rear for side rods and a back weight, and a hole through the sight window for the plunger. Most stabilizer bushings are tapped 5/16-24, which is the near-universal thread, so almost any rod or weight will screw straight in. The plunger hole and the rest mount let the arrow sit at the correct center shot. You don't have to fill every hole on day one, but knowing what each one accepts saves you from buying an accessory that won't thread in.
Is the nocking point a part of the bow, and do I have to add one myself?
Yes and yes. The nocking point is a small marker on the string that fixes where the arrow clips on every single shot, and without it your arrow height wanders, so groups open up. It's not built in, you create it, either by tying it on with serving thread or crimping on a brass nock set. A common finger-shooter starting point is about 1/2 inch above square, though folks run anywhere from 1/8 to 5/8 depending on form and whether they shoot split-finger or three-under. Treat it as a tunable part: set it, shoot a bare-shaft test, then nudge it until your arrows fly clean.
Will any ILF limbs really fit any ILF riser, and where does Formula fit in?
Mostly, yes, that's the whole point of ILF. The dovetail fitting is a shared standard, so an ILF riser from one brand happily takes ILF limbs from another, which is why people mix and match. The big exception is Hoyt's Formula system. Formula limbs use a different mount and are not interchangeable with standard ILF, despite looking similar. Formula tends to lock up tighter and runs a touch quieter, but you can't bolt Formula limbs onto an ILF riser or vice versa, and Formula strings usually run about 1/4 inch longer. Before you buy limbs, confirm whether your riser is plain ILF or Formula.
What are brace height and tiller, and are they parts I adjust?
They're not bolt-on parts; they're measurements that describe how the parts sit together, and you do adjust them. Brace height is the gap from the deepest part of the grip to the string, typically 8.25 to 9.25 inches on a recurve, and you change it by twisting or untwisting the string. Tiller is the difference between the top and bottom limb measurements at the riser; you tune it with the limb bolts on an ILF bow. If you shoot three-under, even tiller is a sensible start. Find your brace by chasing the quietest, tightest-grouping setting, then set tiller and leave both alone.
Community Pulse
What owners and shoppers actually say, quantified across 6 public discussions reviewed in June 2026.
A bare riser-and-limbs is a complete bow on its own
criticismNewcomers keep showing up with just a riser and limbs and ask why they can't shoot. The consensus pushes back hard: a recurve isn't finished until you've added a rest, a plunger and a nocking point at minimum, with sight, tab and stabilizer to follow. Veterans frame the accessories as load-bearing parts, not optional extras, and warn beginners to budget for them.
Add the plunger and clicker right away versus build form on a bare bow first
mixedThere's a genuine split on timing. Some say get the plunger and rest sorted early so center shot is right from the start. Others argue a brand-new archer should shoot off a simple rest, build repeatable form and tune arrow length before bolting on a clicker, since a clicker only helps once your draw is consistent. Both camps agree the parts matter; they disagree on the order you should add them.
All ILF gear is freely interchangeable across brands
mixedMix-and-match is broadly true for genuine ILF, and many shooters happily run one brand's riser with another's limbs. The pushback is about the Formula exception: Hoyt's Formula mount is a separate system that isn't compatible with standard ILF, and people get burned assuming limbs will just drop in. The practical takeaway is to verify the fitting type before buying rather than trusting the label.
How we counted: we read 6 public discussions across archery forums and communities, grouped recurring topics, and counted distinct threads (not comments) where each theme appeared favorably or critically. Summaries are paraphrased in our own words; every count links to its sources. Note: Discussion concentrates on ArcheryTalk's beginner equipment subforum and TradTalk's recurve section. Strongest recurring confusion is accessories vs. core parts (plunger/clicker/sight on a bare riser) and the ILF-vs-Formula compatibility trap. Reddit excluded per instructions.
